Top Lithium Battery 12V 200Ah Lithium Battery Long Life Cycle Rechargeable RV 4WD Camping

TopLi 12-200L is definitely the only drop-in upgrade for your existing old and heavy batteries. You've probably already familiar with the tedious process of replacing a lead acid battery once every two or three years. This is a thing of the past as an investment in TopLi 12-200L lithium battery will give you a much more, a clean and light weight power source that can do EIGHT times as many cycles as your lead acid battery. A cycle is how battery life is measured. Each cycle one full discharge and then one full re-charge of a battery. A standard lead acid battery can cycle approx. 500 times. TopLi 12-200L  can cycle 4000 to 6000 times! Our energy moves the world. You are part of the change !

TopLi 12-200L has developed this  Phosphate (LiFePO4) batteries which are specifically designed as drop- in replacements for lead acid batteries and battery banks. LiFePO4 batteries represent an advancement in safety due to cell design with advanced battery management systems including under and over voltage, over discharge, over current, over temperature, and short circuit protections which ensures safe and efficient operation. TopLi 12-200L LiFePO4 batteries Offers a significant longer cycle life than lead acid batteries helping to minimize replacement cost and reduce total cost of ownership.

The main benefit of the TopLi 12-200L  LiFePO4 batteries is that it weighs considerably less than your existing lead acid batteries. It weighs just 23kg, yes you did read that correctly, just 23kg! You just simply remove your old heavy battery and put the new lightweight TopLi 12-200L in its place. It's as easy as that.



Long Cycle Life 4000-6000cycles@80%DOD.
Maximum support 4 in series or 4 in parallel.
OPLI-12-200(12.8V200Ah)
Electrical Parameters
Nominal Voltage: 12.8V
Rated Capacity: 200Ah
Energy: 2560Wh
Resistance: ≤65mΩ
Efficiency: 0.99
Cycle Life: >4000cycles @1C,80% DOD
Self Discharge: 2% per Month
Cellin Series/Parallel: 4S/2P
Mechanical Parameters
Dimension(L×W×H): 483x170x240mm
19 x 6.7x 9.4"
Weight: 23kg(50.7bs)
Terminal Type: M8
Battery Housing: ABS
Housing Protection: IP65
Cell Type-Chemistry: LiFePO4 Cell
SOC Display(Optional): /
Discharge Parameters
Continuous Discharge Current: 150A
Pulse Discharge Current: 300A (<30S)

Recommended Volt.
Disconnect: 10V
BMS Discharge Cut-off Voltage : 8.8V
Reconnect Voltage: 10.8V
Short Circuit Protection: 300-800us
Charge Parameters
Charge Method: CC-CV
Charge Voltage: 14.4~14.8V
Recommended Float Voltage:13.8V
Recommended Charge Current: 30A
Maximum Charge Current:150A
BMS Charge Cut-off Voltage:15V

Discharge Temperature: -20 to 60 ℃
Charge Temperature: 0 to 55 ℃
Storage Temperature: -10 to 35 ℃
BMS High Temperature Cut-off 65 ℃
