Victron Energy SmartSolar MPPT 250/70-TR SCC125070221

⚡ Victron SmartSolar MPPT 250/70-Tr Solar Charge Controller
Model: SCC125070221

Maximise Your Solar Harvest with Victron's Advanced MPPT Technology

The Victron SmartSolar MPPT 250/70-Tr is a premium solar charge controller designed to extract the maximum possible power from your solar panels while protecting and extending the life of your battery bank. With a maximum PV input voltage of 250V and charging current up to 70A, it is ideal for larger off-grid, RV, marine, commercial and backup power systems.

Key Features:

✔ Ultra-Fast MPPT Technology
Tracks the optimum power point of your solar array continuously, increasing energy harvest by up to 30% compared with traditional PWM controllers and improving performance in changing weather conditions.

✔ High PV Input Voltage
Supports solar arrays up to 250V DC open circuit voltage, allowing longer panel strings and reduced cable losses.

✔ 70A Charging Capacity
Suitable for high-power solar installations with battery banks operating at:
• 12V Systems – up to 1000W PV
• 24V Systems – up to 2000W PV
• 36V Systems – up to 3000W PV
• 48V Systems – up to 4000W PV

✔ Built-In Bluetooth Smart
Monitor, configure and update your controller directly from your smartphone, tablet or computer using the free VictronConnect App.

✔ Advanced Battery Charging
Compatible with:
• LiFePO4 Lithium Batteries
• AGM Batteries
• Gel Batteries
• Flooded Lead Acid Batteries

✔ Intelligent Battery Protection
Adaptive multi-stage charging helps maximise battery performance and lifespan.

✔ Excellent Efficiency
Up to 98% conversion efficiency with fanless cooling design for quiet and reliable operation.

✔ VE.Direct Communication Port
Connect to:
• Cerbo GX
• Ekrano GX
• Color Control GX
• Victron Remote Monitoring (VRM)

✔ Advanced Safety Protection
• Reverse polarity protection
• Over-temperature protection
• Short circuit protection
• PV reverse current protection

Technical Specifications:

• Model: SmartSolar MPPT 250/70-Tr
• Part Number: SCC125070221
• Maximum PV Open Circuit Voltage: 250V
• Maximum Charge Current: 70A
• Battery Voltage: 12V / 24V / 36V / 48V (Auto Select)
• Communication: Bluetooth Smart + VE.Direct
• Cooling: Natural Convection (No Fan)
• Protection Rating: IP43 Electronics / IP22 Connection Area

Applications:

✓ Off-Grid Solar Systems
✓ Residential Energy Storage
✓ Tiny Homes & Cabins
✓ Motorhomes & RVs
✓ Marine & Boating
✓ Agricultural & Remote Power Systems
✓ Telecommunications Sites
